Model: HT / HTS Series
6-Point Impact Sockets
Standard and deep 6-point impact sockets machined to match Hi-TON hydraulic and electric torque wrenches, available for 3/4", 1", 1-1/2" and 2-1/2" square drives, in both imperial and metric nut sizes.
170+ Sizes
21mm – 255mm A/F
Standard & Deep
Standard Socket — Sample Sizes (3/4" & 1" Drive)
| Model No. | Square Drive | Nut A/F (mm) | D1 (mm) | L (mm) |
|---|---|---|---|---|
| HT424 | 3/4" | 21 | 44 | 90 |
| HT441 | 3/4" | 41 | 57 | 90 |
| HT460F | 3/4" | 60 | 82 | 98 |
| HTS24 | 1" | 24 | 42 | 100 |
| HTS55 | 1" | 55 | 82 | 105 |
| HTS97F | 1" | 3.7/8" | 135 | 140 |
Deep Socket — Sample Sizes (1-1/2" & 2-1/2" Drive)
| Model No. | Square Drive | D1 (mm) | T (mm) | L (mm) |
|---|---|---|---|---|
| HTS100 | 1" | 135 | 52 | 143 |
| HT641 | 1.1/2" | 34 | 28 | 130 |
| HT6100 | 1.1/2" | 140 | 75 | 170 |
| HT780F | 2.1/2" | 135 | 62 | 190 |
| HT7175F | 2.1/2" | 255 | 120 | – |
Showing a sample of the full range — 170+ standard and deep socket sizes are available across HT, HTS and HT6/HT7 series. Download the catalogue for the complete size chart.
Download Full Size Chart
